FUJIHD · ELEVATOR DESIGN

Plan the right space
for your elevator.

Explore standard elevator dimensions or share the requirements of your building. Send your configuration to our team to request project drawings.

Start planning
01
Choose your configuration

With a machine room or machine roomless.

02
Review space requirements

See minimum dimensions and maximum car sizes.

03
Request project drawings

Share your parameters and contact details.

FROM PLANNING TO YOUR PROJECT

Clear requirements.
A more useful enquiry.

Use Standard planning to explore the available product configurations. If you already know your building dimensions, choose Custom requirements and send the details you have.

Need help choosing a configuration? Contact our team.

What do the dimension limits mean?

Minimum values show the required hoistway, overhead and pit dimensions for the selected standard configuration. Maximum car dimensions show the upper limit in the product data.

What if some project dimensions are unknown?

In Standard planning, project stops are required and travel height is optional. In Custom requirements, complete the required building dimensions; individual floor heights may be left blank.

How will I receive the drawings?

Choose Request drawings and provide your email and phone number with country calling code. Our team will receive your parameters, review your requirements and contact you about the drawings.

Are these final construction dimensions?

These values support initial space planning. Custom dimensions describe your project and do not confirm a product match. Final layout and installation requirements are confirmed during project review.
